Flexible Customized Durable 1.6mm Safety Stainless Steel Cable Mesh
For Bridge
Stainless Steel Cable Mesh Introduction:
Flexible stainless steel cable mesh is the charateristic leading
product of Anping Yuntong Metal Wire Mesh which has been
manufacturing the product more than 14 years.We have the CE and SGS
certificates.
Stainless steel cable mesh ,also called SS rope mesh, made form
high quality stainless steel wire rope, with the features
ofextremely anti-corrosion and esistant to UV rays, has a long
lifespan in the harsh environments.
| Material | AISI304, AISI316, AISI304L, AISI316L |
| Mesh Type | Ferrule Type,Knotted Type |
| Application | Safety net,anti-theft bag,zoo enclosure,Entertainment facilities
safety mesh,Handrail balustrade mesh,etc. |
| Features | Flexible,soft,anti-theft,strong,durable,support customization |
| Cable Structure | 7*7,7*19,1*19 |
| Surface Treatment | Black Oxidation,Polish,PVC Coated |
| Mesh Size | 0.65x1m,0.95x1m,0.8x50m,1x1m,1x2m,1.5x1m,1.5x3m,2x3m,2x6m,2x90m,custom |
| Mesh Hole Shape | Diamond |
| Angle | 60 degree |
| Wire Diameter | 1.2mm,2.0mm,2.4mm,3.0mm,3.2mm,4.0mm |
| Mesh Opening | From 10 x 10mm to 250 x 250 mm or bigger |
| Color | Black,stainless steel primary color,white,red,blue,custom |
| Sample | Free,but the customer need to pay for the shippingcost |
| Certificate | CE,SGS |
Stainless Steel Cableope Mesh Parameter :
Flexible stainless steel cable mesh is made of AISI 304 or 316
stainless steel wire rope knotted and twisted by hand, which is a
flexible wire mesh. Durable stainless steel cable mesh are
available in a variety of specifications with wire diameters of
various sizes (1.2mm, 1.6mm, 2.0mm, 2.4mm, 3.2mm, 4.0mm) to provide
more protection for various animals.
Stainless Steel Cable Mesh |
| Item | Wire Diameter | Mesh Aperture | Normal Break |
| inch | mm | inch | mm | lbs |
| YT-3212F | 1/8 | 3.2 | 4.75 x 4.75 | 120 x 120 | 1600 |
| YT-3210F | 1/8 | 3.2 | 4 x 4 | 102 x 102 | 1600 |
| YT-3290F | 1/8 | 3.2 | 3.55 x 3.55 | 90 x 90 | 1600 |
| YT-3276F | 1/8 | 3.2 | 3 x 3 | 76 x 76 | 1600 |
| YT-3250F | 3/32 | 2.4 | 2 x 2 | 51 x 51 | 1600 |
| YT-2410F | 3/32 | 2.4 | 4 x 4 | 102 x 102 | 920 |
| YT-2490F | 3/32 | 2.4 | 3.55 x 3.55 | 90 x 90 | 920 |
| YT-2476F | 3/32 | 2.4 | 3 x 3 | 76 x 76 | 920 |
| YT-2460F | 3/32 | 2.4 | 2.4 x 2.4 | 60 x 60 | 920 |
| YT-2450F | 3/32 | 2.4 | 2 x 2 | 51 x 51 | 920 |
| YT-2076F | 5/64 | 2.0 | 3 x 3 | 76 x 76 | 676 |
| YT-2060F | 5/64 | 2.0 | 2.4 x 2.4 | 60 x 60 | 676 |
| YT-2050F | 5/64 | 2.0 | 2 x 2 | 51 x 51 | 676 |
| YT-2038F | 5/64 | 2.0 | 1-1/2 x 1-1/2 | 38 x 38 | 676 |
| YT-1676F | 1/16 | 1.6 | 3 x 3 | 76 x 76 | 480 |
| YT-1650F | 1/16 | 1.6 | 2 x 2 | 51 x 51 | 480 |
| YT-1638F | 1/16 | 1.6 | 1-1/2 x 1-1/2 | 38 x 38 | 480 |
| YT-1630F | 1/16 | 1.6 | 1.2 x 1.2 | 30 x 30 | 480 |
| YT-1625F | 1/16 | 1.6 | 1 x 1 | 25.4 x 25.4 | 480 |
| YT-1238F | 3/64 | 1.2 | 1-1/2 x 1-1/2 | 38 x 38 | 270 |
| YT-1230F | 3/64 | 1.2 | 1.2 x 1.2 | 30 x 30 | 270 |
| YT-1225F | 3/64 | 1.2 | 1 x 1 | 25.4 x 25.4 | 270 |
Difference between 304/316 and 304L/316L:
304 / 316 (Carbon content 0.08) and 304L / 316L (Carbon content
0.03). The main difference is the carbon content.
The lower carbon content ensures the stability of the material at
high temperatures, 304L/316L is suitable for high temperature
environments and places near the sea.
Mesh Aperture/Width:
Along with the wire diameter the mesh aperture width contributes to
the aesthetics such as the level of transparency therefore the
larger the width the more transparent it will be. Another
consideration is the climbing ability, which should be taken into
account especially in public places. Our mesh widths range from
24mm to 300mm.
Different Mesh Types :
The stainless steel cable mesh is hand-made from the stainless
steel wire rope, there are two types: knotted mesh and ferruled
mesh.
- Flexible stainless steel cable mesh (Ferrule type)
The ferrule type series are sub-divided into aluminum alloy mesh
,stainless steel ,tinned copper and nickled copper mesh by the
material of the ferrule. The ferrule type mesh, are more used in
fields like balustrades on WYidges and staircases, large barrier
fences, and building facade trellis systems.
- Flexible stainless steel cable mesh (Knotted type)
Our Flexible stainless steel cable mesh products are supplied in
two main series: Inter-woven and Ferrule Type. Inter-woven mesh are
hand-woven which was also called hand-woven mesh is made from fine
s.s.wire rope . The rope construction is 7 x 7 or 7 x 19 and made
from AISI 304 or AISI 316 material group.
Mesh Orientation:
You can choose horizontal or vertical mesh orientations for the entertainment facilities stainless steel wire rope mesh.
Features :
1. Breaking force, impact resistance,
2. Corrosion resistance, anti-soft resistance,
3. Does not require any maintenance etc.
4. Durable structure, beautiful appearance,
5. New form, one-time investment, permanent use,
Stainless Steel Cable Mesh advantages:
- Lightweight, high-strength, never rust, softness.
- Anti-corrosive, resist the rust, can be repeated use.
- The mesh size and diameter can be modified,so we can make the bags
large or small according to your requirements.
- High strength, strong toughness, free-angles curving and fold,it is
discreet and portable.
- Without toxic material, safety, environmental protection.
- Fatigue resistance, impact resistance, breaking force, the overall
structure of the rugged life of more than 30 years.
Main Applictions:
- Zoo Cages : animal enclosures, aviary mesh, bird cage, wildlife
park, marine park, etc.
- Protective Device : playground fence, acrobatic show protection
net, wire rope mesh fence, etc
- Architecture Safety Net : stair/balcony railing, balustrade, WYidge
safety net, anti-fall net, etc.
- Decorative Mesh : garden decoration, wall decoration, interior
decoration net, outdoor decoration, green wall ,plants climbing
support
Packing And Shipping Details :
Plastic foam and Water-proof Cloth for inter packing ,Fumigated
wooden cases for outer packing.
Delivery: by FedEx, DHL, UPS, TNT EMS, by air, Door-to Door or by
sea.
Lead time:The order could be arranged within 24hours, lead time is
between 7-15 days depending on the quantum of order.
As customer's requirements
FAQ:
Q : Can I get a piece of your products sample?
A : Yes, If the sample is available, it will be free and be
provided anytime. If unavailable, need to customize.
Q : What type of metal mesh does Yuntong offer?
A : we are specialized in the production of metal wire mesh,such as
the stainless steel wire rope mesh,decorative net,metal aluminum
mesh.We have a professional production line of metal wire mesh .
Q : Which payment method you can accept?
Generally we adopt T/T, LC, Western Union, PayPal, Escrow and Money
Gram.
Q : What are fittings and how are they used?
A : We have hundreds of fittings for our stainless steel wire rope
mesh products. Different application scenarios of rope mesh comes
with different accessories,we will provide you with a detailed
installation scheme.
Q : Which countries do you export to?
A : Our products are mainly exported to Australia, Canada, UK, USA,
Germany, Thailand,South Korea and so on.
